Suitable for RGB/RGBW/RGBCCT PWM LED strip.
20KHz high PWM dimming frequency without noise and flicker issue.
Switching 3 output mode via the SET button(RGB/RGBW/RGBCCT).
Need to work with our 2.4G remote control.
Control distance: 30M
Model No. | CH31RF |
| Output mode | RGB/RGBW/RGBCCT |
| Input Voltage | DC12-24V |
Input Current | Wiring connection port: 12A/DC socket: 4A |
Output Voltage | DC12-24V |
Output Current | 15A@2KHz, 12A@20KHz |
Output Power | DC24V: 360W@4KHz, 288W@20KHz DC12V: 180W@4KHz, 144W@20KHz |
Output Type | Constant Voltage |
Input Signal | 2.4GHz |
Control Distance | 30M |
Dimming Range | 1%~100% |
PWM Frequency | 4KHz, 20KHz(default) adjustable |
IP Rating | IP20 |
Warranty | 3-year |
Certification | CE, RoHs, FCC, UKCA |
